Race proven speed sensor as used in race series such as the British F4, GB4 and GB3 Championships. Fitted with a 3 way DTM04-3P female housing and terminated with gold plated pins. Over-sleeved with Polyolefin heat shrink tubing for added cable protection. Cable Length 1000mm - Measured from centre of DTM to exit of sensor. M8 Stainless housing. 2mm sensing distance. IP67 for highest protection in wet environments 360º visible LED indicator. 12v DC 3-wire model - 10 to 32v DC Normally Open (NO) model - NPN
Pinout Pin - Function 1 - 12V 2 - SIGNAL 3 - GND
DO NOT OVERTIGHTEN FIXING NUTS - 8NM MAX
Other connectors and pinouts are available on request, drop us a message, we will be happy to help.
